Do you want to attach sheets to sheets? However, you do not want to rely on riveting, welding, soldering, gluing or folding, but rather create a releasable connection that can be replaced in case of repair? Moreover, have absolute process reliability?
No problem, SHEETITE®, the thread-rolling screw for the direct screwing of sheets, is the solution!
Do you want to attach sheets to sheets? However, you do not want to rely on riveting, welding, soldering, gluing or folding, but rather create a releasable connection that can be replaced in case of repair? Moreover, have absolute process reliability?
No problem, SHEETITE®, the thread-rolling screw for the direct screwing of sheets, is the solution!
Screw sheets directly and securely
When joining or screwing sheets, conventional tapping screws can often cause the screws to over-tighten during assembly or the screws to fail, or the bolted joint to loosen itself after a certain time. This is far from process security. Use the innovative and patented SHEETITE® thread-rolling screw instead for the direct screwing of thin sheets with its increased safety against self-loosening, along with high load-bearing capacity and considerable reduction of installation effort. Compared to sheet metal screws, you can use thinner sheet metal thicknesses, which in addition to material costs can also significantly reduce weight.
How does the direct screwing of sheets work?
To connect the SHEETITE® screw is bolted directly to an overhead sheet with a through hole and a bottom pre-punched sheet.
The screw displaces material in the joining direction, which increases the screwing depth compared to the original sheet thickness. The screw shank assumes a roundish cross-section and thus significantly improves the load capacity.
The SHEETITE® is suitable for joining steel and aluminium (other metallic materials available on request) and does not require any additional securing elements such as washers, nuts or clips. Ideal for the production of sheet metal coverings for ventilation, lamps, machine housings or white goods.
The SHEETITE® thin sheet metal screws are intended for direct screwing (i.e. screwing without existing female thread) of two or more sheets with a total composite of max. 0.5 times the nominal diameter. Your technology advantage:
- optimized load capacity
- high stability and durability
- enormous unscrewing safety due to undercutting
- high security against overloads
- improved hole finding
- enlarged screw-in depth
- higher over torques
- low tapping torque
- no thermal stress on the sheet metal components
- protection of internal product components by rounded tip
- no additional security elements necessary
- option for disassembly
- flexible pre-hole design
- no metal thread, metric thread
- reduction of the weight of the final product by reducing the sheet thicknesses and omission of the security elements
With us, you will always find the right product.
Every single industry requires products that are geared to very specific purposes. To support the requirements of a market holistically, we consistently analyse the current needs and future requirements of our customers.
This resulted in our W.TEC® product series with products for requirements-based solutions and industry-specific innovations. We guarantee optimal and consistent quality and first-class technical service. We can give you expert advice and best practices so that you will always find the right product, be it plastic cabs, slings, screws for thermoplastic materials or many more.
Contact
We are here for you!
In addition to this range of products, contact persons with product and industry know-how are available to advise you.
Contact us on T +45 7320 7320 or via e-mail on product@wuerthindustri.dk.
